This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5873714.

This is a remix, but it works well for the PSVR2.

The remix adds a few choices for the base to add extra weight in the front to reduce tipping over backwards. See the STL files for the base choices. I printed the simple ‘front bar’ one at first and then the black & white layer change solid bottom (no logo) one. There is also another more solid one but with ‘VR’ text embossed into it - not PS branded, just generic ‘VR’.

3/4/23: Added two more bases - thick bottoms. One with a VR logo, the other without.

2/26/23: Added two more base versions that use a small lip at the front so the base has a little ‘tray’ that you can put things like spare parts for your DualSense Edge controller or those silicon ear bud alternate sizes. Just a place to keep them handy. I just printed this one for my final version for personal use.

I printed mine at .28 height / .52 line width with a .4 nozzle / 50% grid infill (for more weight only) and at 90mm/s.

The original suggested using M4x16 screws. I didn't have them, so I ended up using M4x20 self-tapping screws and they worked well.

You can also just use the holes to align the top and base while you apply CA glue.

  • Feb 28 - Added two alignment ‘pegs’ to help those without screws.
  • The round ones print vertically, but will be weaker. The ones that have flat sides and print horizontally should be a bit stronger, but the caps will look ‘weird’ and give a lot more wiggle room and will need more attention to center. I think the glue on the base will be all the strength you need, so I would use the round ones if I didn't have screws to use.
  • Either way, to use these, print two and check the fit and resize in your slicer if you feel you want more or less of a tight fit. Add some CA glue to the base top and then some to each peg before inserting. Insert the pegs, eyeballing the centering a little may be needed, and then just hold for a few seconds until the glue sets enough to hold it for you.

I also used 5 clear rubber cabinet bumpers (about ½") for anti-slip on the bottom of the stand. Any similar type non-slip pads can be used of course.

Images note: the solid base one (no logo) on the PS5 box has the base printed with a layer change so it starts black and then white and then the top is printed black. It is still the 2 part stand.
