Elegoo Arduino Uno R3 and Breadboard Workspace

by

sjcundy

Follow
Follow
Remix Model
Like
Elegoo Arduino Uno R3 and Breadboard Workspace by sjcundy full viewable 3d model
Loading preview...
0 Likes7 DownloadsApril 28, 2022


Community Uploads

No photos added yet, be the first to upload a photo!


0 Likes7 DownloadsApril 28, 2022

Community Uploads

No photos added yet, be the first to upload a photo!

What: - Workspace for Elegoo Arduino Uno R3 and Breadboard - essentially the hardware that comes with the Starter Kits you can buy or standalone. - Two different orientations depending on preference. - Notes: For some reason the bottom left mounting hole of Uno doesn't match up with models that were available. It was offset to the right by ~0.2mm. I am not sure if this is unique to the Elegoo or maybe the model is off but I did adjust and seems to work fine for me.

How: - Printer: Elegoo Netptue 2S - Nozzle: 0.4mm - Slicer: Cura Modified CHEP FF Profile for EN2S - Filament: Overture PLA Black 1.75MM

Why: - Getting back into some electronics work and didn't want the breadboard and microcontroller sliding around the desk. This setup just makes it easier to move aside when I have to get actual work done and not just have fun playing with Arduino.

Where: - Elegoo Neptune 2S - Overture Filiment - Elegoo UNO R3 Project Complete Starter Kit with Tutorial for Arduino UNO
