Simple mount plate for the Zesty Nimble V1 on a Tevo Flash

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:3646222.

A very simple mount plate to bolt a Zesty Nimble to the Tevo Flash. It does require two holes to be drilled in the alu plate that holds the hot end and BL Touch. You can use the Nimble mount plate to position the holes in the right spot and then drill with a 3.5 mm drill.

The Nimble mount plate needs slightly longer screws than the screws used for the hot end and the BL Touch. Use M3x14 screws instead of the M3x10 now in use.

Also included is a filler to fill up the threaded hole for the bowden connector that is no longer used.

The STL models are checked and optimised. The parts that need a different orientation to print properly are rotated to the preferred printing position.

With an installed weight of less than 27 grams on your carriage/effector the Zesty Nimble is the smallest and lightest extruder you can buy, it has ample torque and can be mounted in multiple orientations.

The Nimble is available from Zesty Technology.
