Mount to put 2 Nimbles V1 on a Chimera

by
Zesty.Tech
Follow
Follow
Remix Model
Mount to put 2 Nimbles V1 on a Chimera 3d model
Mount to put 2 Nimbles V1 on a Chimera 3d model
2D
3D
Makes
Be the first to upload a Make
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2701606.

Changelog: Changed the Chimera+ mount, there was 1 hole out of position. Thanks James! Adjusted it and that is now V1.1

Custom plate to mount 2 Zesty Nimbles together on top of a Chimera/Cyclops hot end. The mount plate has two positions, overhanging the fan or rotated 180 degrees. This is instead of the Nimble C/C.

Edit 1: Added the same mount but for the Chimera + and Cyclops + Air cooled. The difference is that the Plus has a filament spacing of 20 mm instead of 18.

The STL models are checked and optimised. The parts that need a different orientation to print properly are rotated to the preferred printing position.

The Nimble Extruder

With an installed weight of less than 27 grams on your carriage/effector the Zesty Nimble is smallest and lightest extruder you can buy, it has ample torque and can be mounted in multiple orientations.

The Nimble is available from Zesty Technology.
