A set of small drop-in hooks, mounts, and brackets for the Gladiator brand slat-wall called GearWall (should also work with GearTrack; let me know if it doesn't). Use the lock in this folder to secure the accessories so they don't lift out when pulling items off of them. I plan on adding more mounts to this collection later, as the need for more arise. The current lock design is a little loose, but it works. I might try to fix that later, but I just don't have time right now.

I searched for some hooks and brackets to use on my Gladiator GearWall but couldn't find ones that met all my criteria (drop-in and sturdy). So, I decided to create my own.

I based the t-slot side on a set of brackets that I found on Thingiverse (https://www.thingiverse.com/thing:4075984). Thanks to the original author for providing the original Fusion 360 design file.

I based the lock on a design I found on Printables (https://www.printables.com/model/597641).

I printed the hooks in Overture Easy Nylon (4 walls and 70% infill) and the locks in Duramic black PETG. The hooks turned out to be surprisingly strong.
