Voron M4 with PC4-01 Bowden Connectors

This is a remix of the beautifully designed Voron M4 extruder.

Since the bowden collet in the original design is a little bit hard to source, I've adjusted the size of the hole to fit a more common PC4-01 connector. Assemble as the original design and screw the connector directly into the printed parts. The fitness may vary from different printers but mine fits tightly (still need to test how long can it last).

Parts needed

Only the main_body and end_plate are modified, and the mirrored version is also included. The other parts and the documents can be downloaded from the voron design github.

Print Settings

The same as the printing guidelines in the voron document (ABS, 4 perimeters with 40% infill).
