Annoying PIggy Bank

The Annoying PIggy Bank, a successor to the Annoying Gift Boxes. A great way to stash your cash thats just simply too annoying to make a withdrawal from. There are 40 bolts and 1 large "vault door" you have to remove to get inside! All parts print support free! There are also 5 different bolt variations so you can make it extra annoying.

There are currently two versions of the container available:

• Piggy Bank Version (Has a coin/cash slot)
• Bank Vault Version (No coin/cash slot)

Dimensions: Inner: 117 mm x 117 mm x 77 mm Outer (Fully Assembled): 125 mm x 125 mm x 107 mm

***Note: The bolts on this design are different than the ones on the other Annoying Boxes. They are longer

Printing Info: These are just the settings I used to test the model, feel free to use whatever settings work best for you. FDM or Resin: FDM Scaling: Can be scaled up, bolts likely won't work well if scaled down. Supports: None Infill/Perimeters: 15% infill + 2 perimeters, 3 perimeters for bolts and screwdriver. Nozzle Size: 0.4 Layer Height: 0.2

Assembly:

• After printing, fix door_panel_2 to the container with 24 bolts
• Place door_panel_1 on top of door_panel_2.
• Fix door_panel_1 in place with door_lock
• Fix door_lock in place with 16 bolts

File List (15):

• container (coin slot) (STL)
• container (no coin slot (STL)
• door_panel_1 (STL)
• door_panel_2 (STL)
• door_lock (STL)
• bolt (flat head) (STL)
• bolt (phillips) (STL)
• bolt (5.5 mm hex) (STL)
• bolt (6 mm hex) (STL)
• bolt (security) (STL)
• screwdriver (flat head) (STL)
• screwdriver (phillips) (STL)
• screwdriver (5.5 mm hex) (STL)
• screwdriver (6 mm hex) (STL)
• screwdriver (security) (STL)
