Replacement Grill Knob
A replacement grill knob. Happens to work with Weber propane grills.
Printing Tips Printing Technology: FDM Layer Height: 0.2mm Perimeters: 6 Infill: 30% Infill Pattern: Gyroid Recommended Material: ABS, ASA Supports: None Support Type: None
Notes: Model is designed to be printed with no supports. ABS, ASA, or other higher temperature filament is recommended.
Clearance for knob can be customized via the Lunar Prototypes website. Default is set to 0.2mm
Recommendations for Reducing Waste:
- Set clearance to best guess (0.2mm works on my printer)
- Import to slicer and cut the body at z = 5mm, unselecting "Keep Upper Part".
- Delete outer ring and print.
- Test on your grill. If too tight, re-customize with a clearance of 0.25mm or higher. If too loose, 0.15mm or lower.
- Repeat as necessary
Customization Instructions Customize the clearance on your Grill Knob directly on the Lunar Prototypes website:
- Navigate: Go to the customization tab.
- Customize: Enter your desired measurements and specific adjustments.
- Submit: Click submit and wait for design to be complete.
Note: The customization system is currently in beta. We are actively refining it, and your feedback is crucial for our enhancements.
