DIY Dock King Fatshark VRX Module Holder for Ground Station

by
JiMaker
Follow
Follow
Remix Model
JiMaker
JiMaker
|
Image 1 of 3
DIY Dock King Fatshark VRX Module Holder for Ground Station 3d model
JiMaker
JiMaker
|
Image 1 of 3
DIY Dock King Fatshark VRX Module Holder for Ground Station 3d model
2D
3D
Makes
DIY Dock King Fatshark VRX Module Holder for Ground Station 3d model
DIY Dock King Fatshark VRX Module Holder for Ground Station 3d model
DIY Dock King Fatshark VRX Module Holder for Ground Station 3d model
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4385426.

This is a project I worked on a long time ago and never really brought to my full vision since I lost interest in FPV / quadcopters and got more into building 3d printers / cnc's. I might put some more work into it though since I'm currently out of work bc of pandemic. So this is meant to mount a standard fatshark dominator / HDO compatible receiver module into this 3d printed box, it's shaped exactly like the goggles so any module that fits into your goggle will fit nicely into this. Just need a PCB and female header pins, some M3 screws.

I'll add more instructions needed as far as the wiring and stuff soon, you can find many DIY projects similar to this on YouTube on great channels such as ":Drone Mesh".

I put a lot of time into perfecting this design, I was originally planning on selling the plans to it but never did fully flesh out my vision. But if there's enough interest I may put some more work into it. Just let me know in the comments what you'd like to see (1/4-20" nut for mounting to tripod, etc). Tips are very much appreciated especially during these hard times since I'm running on what little savings I have and what little side work I can find.

YouTube - Printed Part Preview

YouTube - Working Prototype
