This model is restricted by licensing terms.
2 Likes33 DownloadsJuly 22, 2022
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2967271.

20mm disk mount for Tower Pro MG946R servo.

Disk diameter: 20mm Disk thickness: 2mm Center hole diameter: 3mm Outer hole diameter (with holes version): 1.5mm Outer hole distance from center (with holes version): 8mm

They should be a tight fit and might need a gentle push.

Will possibly fit other servos that have a ~6mm diameter, 25 tooth shaft with M3 thread.

This design is completely free and shared under a permissive license. Your support is hugely appreciated.

Did you know?

Some of our designs cannot be found on Thingiverse. If you are looking for more, check out our premium projects:

https://codeandmake.com/premium

Printing
  • Resolution: 0.1mm - 0.2mm
  • Infill: 100%
  • Supports: Doesn't Matter
  • Rafts: Doesn't Matter
License

"Tower Pro MG946R (55g) Servo Arm Disk Horn Round Mount (20mm)" is licensed under the CC BY license by Code and Make.

We are proud to offer content to you absolutely free.

We love to create free content for you. As you might imagine, it takes a lot of time. Supporters help us fund materials and equipment to create future projects and tutorials. To show your appreciation, please use the link below:

https://codeandmake.com/support

We thank you so much for your support!
