Side Rail Mount for Ender 3 Stock LCD Case

by
The-EG
Follow
Follow
Remix Model
Side Rail Mount for Ender 3 Stock LCD Case 3d model
2D
3D
Makes
Be the first to upload a make
This model is restricted by licensing terms.
0 Likes3 DownloadsOctober 18, 2021
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4761038.

This is an alternate mount for the 'Ender 3 stock lcd case.' I like that case, and decided to use it to mount an old LCD to my new Ender 3 v2, to replace that DWIN LCD that sadly doesn't work well with Marlin/Octoprint (yet).

But, unfortunately, the rails on the Ender 3 v2 are not threaded where the LCD would normally mount on the v1 and Pro models. So I created this mount that mounts on the side of the rail instead.

Use M3 bolts (10mm or so) and these v-slot nut adapters: https://www.thingiverse.com/thing:3050607
