Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2648748.
Just bought a new BMPCC because the HDMI broke on the last one. Wanted to make sure that didn't happen again, but didn't want to shell out for a new case. Probably not too useful unless you have:
D Focus Cage http://amzn.to/2zJahdE
Hdmi Adapter http://amzn.to/2jtYCco
For the screw I used an old m4 screw I had lying around. It doesn't fit the screw hole actually. I think it's american threaded, but I can get 3 turns out of the screw before it becomes a problem, so I thicken the bracket to have it tight.
Also build some thickness inbetween the micro hdmi connection, This is because there's a sizeable gap and to prevent the port from braking if it falls onto the hdmi port.
