Gift Box Series This is the fourth gift box in a series of boxes that I’m designing for Christmas this year. All the boxes are similar in size and shape but each one opens differently. If you print one I would love to see it, be sure to post it here or tag me on your socials.

I hope everyone enjoys printing them as much their loved ones will enjoy receiving them! 🎅🎁

Gift Boxes Season 1 Gift box #1 Gift box #1 Quantum Addition Gift box #1 Print-In-Place Gift Box #2 Gift Box #3 Gift Box #4 Gift Box #5 Season 2 Gift Box #6 Gift Box #6 Print-in-Place Gift Box #7 Gift Box #7 Print-in-Place Gift Box #9 Gift Box #10 Gift Box #11 Print-in-Place


Gift Box #5 To remove the top of this box simply press on one set of ribbons just below the top. These ribbons are actually complaint catches that flex when pressed to unlock the top.

The box is roughly 100mm x 100m x 80mm tall.

Print Instructions None of the parts require supports. The bow and ribbons are printed separately and glued on. I printed all the parts in the orientation provided. I prefer the vertical orientation for the ribbons for a smoother surface finish, and they are much stronger printed in this orientation. I added helper pads to the ribbons to help keep them stable and adhered to the bed during printing. I printed everything at .2 layer heights but the box and ribbons could definitely be printed at a larger layer height without issue.

I used Gorilla Glue(aff.) for gluing on the ribbons. Put the glue in the middle and let it naturally spread out. If you don’t own as set of these clampsyou should pick them up, they really help with gluing the ribbons on.

Printed on the Muldex rep-rap IDEX printer.

Printed with Polyalchemy Elixir

Note: Assembly model for reference only.

Support and Licensing If you would like to help support more free models, or gain permission to sell physical copies of my models, consider joining my Patreon

Valentines Day, Birthday, Holiday
