Google Nest Hub Articulated Arm Mounting Bracket

by
ulsmith
Follow
Follow
Remix Model
Like
ulsmith
ulsmith
Image 1 of 2
Google Nest Hub Articulated Arm Mounting Bracket 3d model
2D
3D
Makes
Google Nest Hub Articulated Arm Mounting Bracket 3d model
Google Nest Hub Articulated Arm Mounting Bracket 3d model
2 Likes13 DownloadsJuly 14, 2022


There is a few out there to be fair, but none that offered what i wanted which was a flat screen TV style mount.

So here is my own articulated nest hub bracket. Comes with various size arms and the ability to add as many or little arms as wanted to get desired reach.

Requires a few screws, M3x14/16 should work, holes should self tap.

Has a nice tight ball joint on the end for final tilting... plug in the ball into the socket with the flats matching, then twist 90 degress (might need pliars or a vice, can be a little hard), this will lock the ball in place. Ball joint is pretty tight at first.

ring slips over nest hub base once unplugged, snug fit...

Printing: Make sure you print the wall mount 100%, this is the week point in the whole setup, i hav made this slightly smaller and stronger so you can print 100% infill

Enjoys peoples!!
