Replacement Feet for Salter Digital Kitchen Scales

by
peaberry
Follow
Follow
Remix Model
Like
Replacement Feet for Salter Digital Kitchen Scales 3d model
2D
3D
Makes
Be the first to upload a make
This model is restricted by licensing terms.
0 Likes15 DownloadsJanuary 24, 2022
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:3742080.

I've had these Salter Digital Kitchen Scales for many years, but the plastic/rubber feet recently disintegrated, rendering them completely useless. Rather than throw out the scales, I printed these replacements in PLA and they are working nicely again now.

The feet are designed to accommodate the metal disc taken from the old feet (the only part that survived), and can be secured with the original screws. I printed them upright without supports (the bridging didn't seem to be a problem).

The mounting holes are 2.6mm diameter and 21.8mm apart, the internal diameter is 16.6mm, the larger outside diameter is 22mm and the diameter of the foot that projects from the case is 15mm. Overall height is 9.5mm.
