MPCNC Burly - 65mm Spindle bracket with pen attachment

by
newtechcreative
Follow
Follow
Remix Model
MPCNC Burly - 65mm Spindle bracket with pen attachment 3d model
MPCNC Burly - 65mm Spindle bracket with pen attachment 3d model
2D
3D
Makes
Be the first to upload a Make
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4172656.

Here is my 65mm Spindle mount/bracket for the MPCNC. This was made for the 1.5kw spindle and holds VERY well and secure. Designed with cooling channels and two screws for tool adapters for example the pen mount also included. Insure to install hex head screws before adding spindle.

The Pen mount can mount a horizontal item for creative mounting as well as the traditional vertical mount for pens ect.

NOTE: This is not for palm routers with wide head. The design is too close to rails for a palm router.... only use for spindles.
