Fox.SLDPRT

Thor Hammer

hammer.SLDPRT

Pencil holder

Pencil holder_V2.STL

 Internal gear

Internal gear.STEP

Spiralized Octet Truss Modular Snap Struts

Display Only.stl

No.8 - Light Up Octiman

Head.stl

Gridfinity TS100 soldering iron holder

Holds the TS100 and three tips vertically.

Torus Vase

Torus Vase.STEP

The Infinity Vase

Infinity Vase.STEP

Solidworks 2022 Parametric Baseplate for Voidstar Lab's Gridfinity

This is a Solidworks parametric version of the Gridfinity Baseplate (Heavy and lightweight) from Zack Freeman form Voidstar Labs.
Original File: https://social.thangs.com/m/60925
This file is fully parametric, you can change de variable values in the "Equation" folder or modify everything in the FeatureTreeManager.
I have added a few extras feature to the original design. Please locate the "Optionals" folder and try the followings:
-Toggle between the Heavy and Lightweight version by supressing/unsupressing "Lightweight-Cut" feature or change configuration
-Toggle an extra contour to make the grid precise fit your drawer by supressing/unsupressing "Outer-Edge-Thickness" Feature. You can change the X and Y values individually in the equation.
-Toggle between engravable coordinates for each grid unit by supressing/unsupressing "Coordinates" Feature. The font side and depth might need to be fine-tuned.


Solidworks Parametric Baseplate for Voidstar Lab's Gridfinity

Steelix Pokemon Flexible 3D Model

Pokemon Steelix Model
Flexible model, No Support Required
Easy to Print

ESPADA ALADDIN. SLDPRT

Computer Desk

Escritorio 1500 x 600 x 850

Self-Orienting Ratchet Socket Wrench

Frame.stl

Ender 3 S1 motherboard cover 80mm fan

New to Onshape and making 3d models, so it's pretty basic but this allowed me to put a Noctua NF-A8 FLX 80x80x25mm fan right below the motherboard, I didn't see how the other ender 3 ones could work. Holes might be a little small depending on how your mounting, i used rubber mounts they include in the box, had to drill them a hair, its a stretch but they do fit. Also i didn't see an easy spot to bolt the rear of it to, so its just the front screw and side one. My first attempt was designed upside down so I had to mirror it and reprint, the pics are of the 1st print for those wondering. Step file included for those more talented than me.

Compression spring - 90N

A working spring that generates about 90N (can hold 9kg) at solid length (without cracks or damages). Fatigue test has been performed up to about 4000 cycles without any damage (decay within admissible range of 5%). However according to calculation, it should have infinite life (engineering speaking).

⚠ ATTENTION ⚠
This spring is designed taking into account mechanical properties of PLA+. Any different material or setup will impact the declared performances.

☝ Do not scale the model. Any dimension change would impact performances and resistance.
✌ Print with 100% infill (layer height no more than 0.2mm). Printing direction is vertical with supports between coils. They will be easy to remove.
🤙 Make sure your printer is well tuned and you get proper layer adhesion.

📚I won't be explaining the whole design process that guarantees functionality and performances, but if you are interested you can contact me.

Also, if you need a specific spring of specific load, do not scale the following one cause it won't work. Spring has to be designed accordingly.

Data of the current spring:
Free length = 100mm
Outer diameter = 50mm
Inner diameter = 30mm
Solid length = 69mm ca.
Max force @solid length = 90N ca.

Ender 3 Pro Filament Guide Rev1.0

**My first ever CAD design, and self designed 3d print.**
I created this as I was having issues with the filamant location causing the filament to bend too far and bind. This reduces the angle as it enters the feed motor, reducing load and slippage.

 It is not optimized for overhangs, as I don't know how yet, so support material is a must!
I use a 50% infill to reduce plastic waste, since this part is not under alot of load.
Prints, easily direct to bed, with no skirt, brim, or raft.

Knob.SLDPRT

Knob , you can resize it to make it fit with your switch.
 Using solidwork

ButterDishCover.SLDPRT

This is a cover (lid) designed for a butter dish. It can be placed onto the dish into its grooves over any items that need to be protected from dust, flies, etc.
The thickness of the cover is 3mm.
Dimensions: 146 x 91 x 83.6 mm
CAD Files for the butter dish can be found in my account.
