Equal Space Divider Locking Pin

by
rpjamess1
Follow
Follow
Remix Model
Equal Space Divider Locking Pin 3d model
2D
3D
Makes
Be the first to upload a make
This model is restricted by licensing terms.
0 Likes3 DownloadsOctober 30, 2021
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:3898713.

While I love the design of this divider, I knew I would have an issue with keeping the spacing while I was marking. All I needed was a pin that could be tightened to provide either a little or a lot of friction.

I have included the Fusion 360 file in case not everyone has small M3 screws like I do. You can edit the threads to go longer.

Also, depending on your printer, you male have to drill out the hole on the female pin. My bottom layer squished and made the hole too tight.
