Very custom fan vent cover to prevent unwanted airflow though an unused fan vent. I don't know how pipe sizing works so heres some vague measurements of the wall plate (without fascia piece):
- Outer diameter of grid holes: 96mm
- Outer diameter of wall plate: 134mm
(Ignore the printing defects of the curved surface of the plate).
This design is licensed under CC BY-NC-SA 4.0.
