No nonsense part cooler for FT5 Titan Volcano BLTouch combination

by
WalterSKW
Follow
Follow
Remix Model
No nonsense part cooler for FT5 Titan Volcano BLTouch combination 3d model
No nonsense part cooler for FT5 Titan Volcano BLTouch combination 3d model
2D
3D
Makes
Be the first to upload a Make
This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:1972011.

NEW Version with shorter nozzles download the V7

With the close BLTouch mount, I needed a new compact partcooler for my volcano. I want to use large nozzles and change nozzles quite often. The heater block should be accessible for a good grip. Cooler has to fit between BLTouch and Volcano.

This is the result. Design may still change a bit. I did already some tests with good results. This is the latest version with some improvements : inclination of the outlets, fixation block more robust.

I used a special part to fix the cooler from this design

Added a 6th iteration : Moved the fan inline with the nozzles to get a more equal airflow through both nozzles. cleaned up/streamlined the initial model a bit, changed the support to give more freedom for adjustment in Y-direction. Made it a bit longer to the back. Space enough in the FT5. Picture is still from a beta version

Normally I can keep the bed temperature at 75°C, with the first tests of this cooler I got a thermal runaway from the bed after switching to 100% from layer 20 on (6mm). Same fan.

Trick : put a layer of adhesive aluminium tape on the side of the outlets facing the hot end. The PLA-testversion didn't even move/flex after printing 3 hours@240°C. Tape used for insulation purposes works great!

Tip : Use 3d-Tool to have a detailed look on this thing
