Raspberry Pi GPIO Power Blocker for Prusa

by
Shwalamazula
Follow
Follow
Remix Model
Raspberry Pi GPIO Power Blocker for Prusa 3d model
2D
3D
Makes
Be the first to upload a make
This model is restricted by licensing terms.
2 Likes5 DownloadsDecember 20, 2021
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4614362.

Blocks most GPIO pins of a Raspberry Pi board for connecting the Pi to the Prusa Einsy board via GPIO using the Prusa Pi-Zero W installation guide:

https://help.prusa3d.com/en/article/raspberry-pi-zero-w-preparation-and-installation_2180

Power pins are blocked as well.

This works for connecting any Raspberry Pi to the Prusa Einsy board. Remember to configure your Bluetooth pin to a serial pin to make the connection work.

Note Anything other than a Pi-Zero W will need to be externally-powered.
