Ridgid R4514 Pro 10in. Jobsite Table Saw Fence V1 Slider (P/N 089240028112) 3d model
Ridgid R4514 Pro 10in. Jobsite Table Saw Fence V1 Slider (P/N 089240028112) 3d model

Ridgid R4514 Pro 10in. Jobsite Table Saw Fence V1 Slider (P/N 089240028112)

This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4336504.

I have a Ridgid R4514 Pro 10 in. Jobsite Table Saw, on which I broke the little springed sliding retaining fingers off the fence slide while removing the fence. I could probably have them replaced under the warranty or the lifetime service agreement, however I wanted my saw fixed asap, so I modeled one.

This part is labeled "V1", but the actual part number in the parts list is 089240028112 (seen here in Figure F as 12, Slider: https://ridgid.ordertree.com/media/models/docs/1031/R4514_836_r_01.pdf)

This thing was made with Tinkercad. Edit it online https://v1.tinkercad.com/things/8fzTvIszlj7


Discussions

Ridgid R4514 Pro 10in. Jobsite Table Saw Fence V1 Slider (P/N 089240028112)

19 downloads · 4 years ago
