Here is a holster for my Leatherman Wave Classic (the original Wave tool) multitool. I like that I can remove and replace the multitool with one hand, quickly and easily. Other holsters I have seen rely on friction or a flap to keep the mutlitool in-place; not either convenient nor secure for my needs.
The holster retains the knife in position with a Neodymium magnet. The holster secures to your belt with an integrated belt clip. The belt clip supports belts up to 38mm (1.5in).
I use a salvaged Neodymium magnet from an old 3.5in hard drive, used without the metal plate. The magnet is curved and about 31 x 13 x 1.25mm in size. Other similar sized magnets may work, but test the magnetic hold strength to ensure that the tool can be held in-place during your intended activities. I secured the magnet to the printed holster with CA (Super) glue.
The belt clip attaches to the holster via two self-tapping countersunk 3mm x 7mm screws.
To note, the current Leatherman Wave tool is the Wave+. Unfortunately, the tool dimensions have changed enough to not fit into my current holster design. If someone can direct me to complete and accurate measurements for the current Wave+, I'd consider releasing a revised holster to fit.
My print is made in 1.75mm eSUN PLA+ filament, with 0.2mm layer height and 15% infill on a Bambu X1 Carbon printer. Print supports are not required. Parts are by default orientated in the way I printed them on the print bed, which should give it maximum strength. Probably wise to include a brim when printing the belt clip part vertically.
I hope you can find this print useful, too.
