Ender 3, Ender 3 Pro Electronics Enclosure (Updated)

by
peterz
Follow
Follow
Remix Model
peterz
peterz
Image 1 of 2
Electronics enclosure. power supply and control panel
Ender 3, Ender 3 Pro Electronics Enclosure (Updated) - Electronics enclosure. power supply and control panel - 3d model
2D
3D
Makes
Ender 3, Ender 3 Pro Electronics Enclosure (Updated) - Electronics enclosure. power supply and control panel - 3d model
Ender 3, Ender 3 Pro Electronics Enclosure (Updated) 3d model
This model is restricted by licensing terms.
30 Likes56 DownloadsMarch 25, 2022
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5232610.

This enclosure is designed to hold all the electronics for the printer. It holds the MeanWell power supply, controller board (4.2.7), front control panel, Raspberry PI 4 and a buck converter to power Raspberry PI. Included in the files is a doc that lists many helpful items to perform the relocation of the electronics. All parts were printed using PLA from various vendors. I have added 2 files to support the original Ender 3 Power Supply.
