Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4391674. Bearing mount to suit IGUS Drylin RJ4JP-01-08 linear bearings and LM8UU types. This was designed to replace the Y axis bearing mounts on the CTC i3 DIY, and the bearings sit at the same height and with the same hole spacing as the original (also pictured). The bearing is secured with a single cable tie (2.5mm wide), primarily to keep the overall height as low as possible. The overall dimensions are 42mm x 28mm x 18mm height (with the bearing fitted). The mounting holes are 32mm apart and suit M3 screws.
