Sovol SV01 filament guide

This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4882347.

I use the SH-01 filament dryer with the Sovol SV-01 and placed it on the right side of the printer. I wanted a better way to guide the filament from the top of the SH-01 into the filament sensor mounted on top of the printer using this sensor holder form JSchulze: https://www.thingiverse.com/thing:4702282

This utilizes the bolts and wing nuts that came with the stock filament holder on the SV-01.

Would most likely fit other printers with similar framing.

UPDATED: 9/17/2021 "Straight filament guide updated" file has the logo removed, mount holes slightly resized, and the angled roof section above the screws re-worked to print cleaner.
