These brackets will allow you to liberate your Thrustmaster T-LCM pedals from the OEM plastic housing. Please note that the flexing in the demo video is from my Amazon dropshipped sim rig, the brackets themselves are solid as a rock.

If you would like these CNC machined, you will have to edit the parametric file linked here. The PCB mounting holes are designed for the OEM self-tapping mounting screws.

All OEM parts carry over besides some fasteners you can find at your local hardware store. These are outlined below.

Print specifications (based on Bambu Lab PLA Basic in Grey and Cura's Balanced - Normal preset) Wall Line Count: 5 Infill Density: 40% Infill Pattern: Gyroid Slicing Tolerance: Exclusive (very important that this is set, it will ensure proper fitment!) Support blocker placed in M8 threaded hole

Mounting Specifications 8mm (⁵/₁₆ in) mounting holes Front to rear hole spacing (all): 132mm (5 ¹³/₆₄ in) Throttle-clutch side to side hole spacing range: 16mm (⁵/₈ in) -> 42mm (1 ²¹/₃₂ in) Brake side -> side front hole spacing range: 12mm (¹⁵/₃₂ in) -> 32mm (1 ¹⁷/₆₄ in) Brake side -> side rear hole spacing: 32mm (1 ¹⁷/₆₄ in)

Non-OEM prerequisites 3x M8 hex head screw no more than 24mm in length (these are to limit the upper travel to allow spring retention) 12x M8 socket head screw (these are to mount the brackets to a rig) 15x M8 (#6) washer no more than 16mm (⁵/₈ in) in diameter (these will mitigate some of the deformation that comes with screw tension)
