SawStop Blade Guard Vacuum Cap

by
markmoran
Follow
Follow
Remix Model
Like
SawStop Blade Guard Vacuum Cap 3d model
2D
3D
Makes
Be the first to upload a make
1 Likes3 DownloadsMay 12, 2023


The SawStop Blade Guard includes a 1 ¾" vacuum port, but when not using the Blade Guard (e.g. for narrow cuts), you want to cap that vacuum hose so the suction is not being wasted.

This is just a 1 ¾" (46mm) diameter circle extruded 15mm high. Includes Fusion 360 file.
