I was unhappy with the amount of vibration transfer with most solid/rigid models I could find online for the berdair MAX pump, so I decided to just hang it with a rubber band. I ended up designing a quick bracket that I could use to hang it easier. There is still noise from the pump and a hissing sound as air escapes the tiny holes surrounding the hot-end, but vibration transfer between the pump and the frame of my printer is completely eliminated. Files are meant to work with 2020 extrusion and M5 flat head bolts with T-nuts.
