Lithophane Lantern

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5666695.

This sleek lithophane lantern is a perfect holiday gift for your loved ones! Just print the standard parts (Cap, Top, Lamp, Light, Base) in a color of your choosing and then print 4 lithophanes using the settings below. After a quick assembly, you will have a perfect gift!

Build Video: https://youtu.be/2O5LfKkQI_8

Lithophane settings: https://lithophanemaker.com/Framed%20Lithophane.html Frame Options: Frame Only Lithophane Resolution: 0.2 Base Length: 100 Base Width: 7.5 Base Height: 7.5 Overhang Angle: 45 Maximum Thickness: 3.0 Minimum Thickness: 0.6 Height: 150 Support Thickness: 2 Support Angle: 75

Purchased Parts: LED Strip: https://a.co/d/6RMyemb Battery Box: https://a.co/d/iZDi6kF M4 Threaded Insert: https://a.co/d/0o1zLzP M4 Bolt: https://a.co/d/ijiEiE7 Top Ring/Handle: https://a.co/d/gkiZQXM Joining Dowel: 1/4 x 1-1/4" Build PLA: https://www.matterhackers.com/store/c/mh-build-series?aff=7604


13 Likes56 DownloadsNovember 30, 2022
