This is a remix of Zach Freedman's excellent Gridfinity Mitutoyo caliper holder. I didn't have the need for spare batteries, but I did need a place to stick a steel ruler and a fillet gauge (https://www.thingiverse.com/thing:1184315)

Original: https://thangs.com/designer/ZackFreedman/3d-model/Gridfinity%20Caliper%20Holder-62216

I've included the Fusion 360 source so you can adjust. Note that some filaments expand (especially the one pictured), so you may want to expand the clearances. Or just sand the inside a bit with a rasp as I did. Normal PLA prints perfectly fine as is.
