Mounting Grid for 0.1" Spaced PCBs

by
darren.pruitt
Follow
Follow
Remix Model
Mounting Grid for 0.1" Spaced PCBs 3d model
Mounting Grid for 0.1" Spaced PCBs 3d model
2D
3D
Makes
Be the first to upload a Make

Adafruit has the Swirly Aluminum Mounting Grid for 0.1" Spaced PCBs and included a link to a KiCad python script to generate the same. But I don't have or know how to use KiCad but I do know how to use Fusion 360.

Using the description I created the sketch for one of the squares and used pattern to extend it to a 5x10 grid.

EDIT: Added grid sizes 2x10, 5x5, 5x10 and 10x10.

All credit goes to Adafruit.
