Model Y Made-In-Austin 4680 Jack Pad with Magnet Pouch.

by
Nalla217
Follow
Follow
Remix Model
Model Y Made-In-Austin 4680 Jack Pad with Magnet Pouch. 3d model
Model Y Made-In-Austin 4680 Jack Pad with Magnet Pouch. 3d model
2D
3D
Makes
Be the first to upload a Make

Tesla's limited run of Model Ys made in Austin, Texas with 4680 cells has a jack point locator hole that is smaller than other USA made Teslas. The smaller locator hole means that most other jack pads made for Teslas will not fit in the hole. This is my (untested) jack pad. It has a void in the stem to place a 10x2 N52 magnet into place while printing the part. My initial non-load-bearing test found that the aligned Z-seam provided enough friction to hold the jack pad in place.

Use at your own risk when lifting your 4,480 pound Model Y. Use equipment that is rated to hold the weight of your vehicle, use ppe, and print with high-density infill.
