Dremel model 220 workstation replacement gear

by
DondeEstaLaBiblioteca
Follow
Follow
Remix Model
DondeEstaLaBiblioteca
DondeEstaLaBiblioteca
|
Image 1 of 2
Dremel model 220 workstation replacement gear 3d model
DondeEstaLaBiblioteca
DondeEstaLaBiblioteca
|
Image 1 of 2
Dremel model 220 workstation replacement gear 3d model
2D
3D
Makes
Dremel model 220 workstation replacement gear 3d model
Dremel model 220 workstation replacement gear 3d model

This gear is a replacement for the gear in the Dremel Model 220 workstation. To mount it to the original shaft simply hammer it in and it will hold well. I recommend printing it in PLA+ for it's high resistance to abrasion or another high strength material like PC. print with 100% concentric infill or with infinite perimeters. Print it on the flat side. Requires no supports. Remember to pre-tension the spring and set the set screws tight so there is no play and also lube with a plastic safe grease like Super Lube. If there are any questions leave a comment. Enjoy!


2 Likes9 DownloadsJune 19, 2024



2 Likes9 DownloadsJune 19, 2024

Instructions

Filament • 0.2mm

MaterialPLA+
Layer height0.2 mm
Infill density100 %
SupportsNone
