Get commercial license and download newest models cheaply- https://www.patreon.com/goodesign
The Falcon 9 rocket and dragon capsule are successfully launched and in operation. Perhaps that's why the previously made Falcon 9 rocket and Dragon Capsule models were also very popular. And there was a request to continuously produce Falcon heavy.
However, Falcon Heavy is a very large project and I was hesitant because it was a time-consuming task. However, it started to be produced at the constant request of customers, and it was finally completed.

Second stage and fairing are not included.
Second stage link - https://than.gs/m/1318677

Fairing link - https://than.gs/m/1299069

The composition of the parts is as follows.
X2 means you need 2 sets, X12 means you need 12 sets. So, you need to print as many more as you need.
Inter Stage Min
Inter Stage Side x2
Inter Stage Hinge x2
Side Cable Main
Side Cable Side x2
FH Main
FH Side x2
SpaceX Side
SpaceX Side x2
Middle Main
Middle Side x2
Bottom Main
Bottom Side x2
Booster Main
Booster Side x2
Landing Leg Bar x12
Landing Leg x12

If you've ever built a Falcon 9 rocket, it's easy to do.
Please check the video for the assembly process.

https://youtu.be/DfAIVl9LiVo

Scale 1 : 66
Size when finished, X 233mm, Y 81mm, Z Fairing 1058mm, Second Stage 936mm, Heavy 730mm

SpaceX Falcon heavy

GOODesign_Booster_Main.stl

Get commercial license and download newest models cheaply- https://www.patreon.com/goodesign
Projects in Space X are going well now. With the success of several launch trials, the form of the prototype is gradually taking shape. The Starship prototype we designed before became very popular, and customers continued to ask for the complete Starship design, so this time we designed this for Starship Cargo.

Its main features are:

1. Depicted a honeycomb-shaped heat-resistant tile that protects the hull from burning when the Starship enters the atmosphere.
2. The design of the booster has been changed to the form that is currently being produced.
3. A structure that opens and closes the hangar is applied.
4. A structure has been created that can load specific cargo inside the hangar.

https://youtu.be/c9b7t_SXMwY

caution.
1. To make the booster stronger, set the Infill to 30% or higher.
2. Fix loose parts more firmly with adhesive.

If you are having problems with printing, check out our printing tips.

https://fab365.net/print-tips-list

In the future, I plan to make a number of Space X products as designs for 3D printing.

Please submit your requests to Fab365 Requests.

Scale 1 : 144

Biggest part size x 63mm, y 63mm, z 184mm

SpaceX- Starship Cargo

GOODesign_StarShip_Booster.stl

Get commercial license and download newest models cheaply- https://www.patreon.com/goodesign

This Starship Crew model was designed by referring to the images provided by SpaceX and the prototype currently being built.

A great feature of this design is the maximum expression of the cabin where the crew stays. For this, we have consulted a lot of various materials. This may be different later on.

The window at the top is designed to give you two choices.

1) One is that the window and frame are printed together, and it is completed by painting the window frame.

2) Another method is to print the thin window frame separately and attach it to the window. If the surface of the window and spacecraft body is rough or irregular, it may not stick well, so please check each surface carefully before applying the adhesive.

The lower windows have different lengths, so please check each length in order before inserting.

The upper body is designed with a detachable upper body for viewing the inside of the crew compartment.

Please see the video for details.

Building process of Starship Crew - https://youtu.be/te3qFyoSTbE

I am really looking forward to whether it will be possible to build a colony on Mars.

Scale 1 : 144

Biggest part size x 106mm, y 115mm, z 184mm

SpaceX Starship Crew

GOODesign_StarShip_Lower_Part_Tile.stl

Get commercial license and download newest models cheaply- https://www.patreon.com/goodesign
The Falcon Rocket X has really won a lot of people. Accordingly, there is also a flood of requests to make related things. Among them, there were a lot of requests to make 'Second stage' as soon as possible with regret for excluding the 'Second stage'. So this time, the 'Second stage' was produced together with the 'Inter stage'.
The second stage and interstage we designed this time can be removed from the top two of the existing Falcon Rocket X components (this is the interstage and the second stage) and put them in place. Please refer to the video!

The composition of the parts is as follows.
cap1
cap2
cap3
PAF(Payload Attach Fairing)
second stage body
second stage booster
second stage inter stage

Caps 1, 2, and 3 are placed on the PAF and are used when the Second Stage returns to Earth.
In place of Caps 1, 2, and 3, previously produced fairings and satellites can be installed.

https://youtu.be/0dMeJkpZjeg

Stay tuned for the next Space X series!

Scale 1 : 66
Size, X 64mm, Y 64mm, Z 262mm

Falcon 9 second stage

GOODesign_Second_Stage_Inter_Stage.stl

Get commercial license and download newest models cheaply- https://www.patreon.com/goodesign
Designed for 3D printing of Space X's important space programs, the Dragon capsule and Falcon 9 Rocket have gained a lot of popularity from customers. And, of course, there were many requests to create a design product related to this.
There are two, Fairing and Falcon heavy. Of these, we first produced Fairing, which takes relatively little development time.

Download Falcon9 rocket - https://than.gs/m/1265150

This Fairing is designed to replace the Dragon capsule on the previously created Falcon 9 rocket.
In addition, I have designed a satellite that can be mounted inside.
The satellite was designed so that the solar panels could move, and the arms connected to the solar panels could move together.
※ Fairing L and R can fall during printing, so I recommend using Brim. ※

The process of making after printing is as follows.
1. Push up the front panel of the satellite and press it into place.
2. Press and insert the solar panel into the connection bar next to the body. After connecting, unfold the solar panel and check that the connecting rods are fitted.
3. Press and connect the ring-shaped part (PAF connection part) to the bottom of the satellite.
4. Put the satellite on top of PAF (Payload Attach Fitting).
5. Fold the Parabolic antenna part and attach it to the Parabolic antenna on the front with adhesive.
6. After placing the PAF and the satellite on the desk/floor, hold each fairing in one hand, and connect the fairing to each other as if covering the PAF and the satellite.
7. Remove the dragon capsule from the Falcon 9 rocket and place the fairing on it.
Please refer to the video for the detailed process.

https://youtu.be/l1OYui2OPco
https://youtu.be/hAr2QwTX3gs

Falcon heavy is also in preparation, so stay tuned!

Scale 1 : 66
Sentinel size = X 80mm, Y 104mm, Z 90mm / Sentinel Part size = X 22mm, Y 22mm, Z 10mm, X 27mm, Y 27mm, Z 2mm, After folding X 49mm, Y 55mm, Z 96mm

SpaceX Falcon 9 fairing

GOODesign_Foldable_Falcon9_Fairing_L.stl

Elon Musk is a true pioneer of this era. He broke the existing framework and it has gained the support of many people. This is a fresh shock to many who firmly believe in the existing order. He accelerated the popularization of electric vehicles, spread progressive designs to the public through cyber trucks, and finally began a full-fledged private space project.

Celebrating the launch of his successful spacecraft this time, I designed a dragon capsule and trunk.

This design is not foldable, but the capsules and trunk are fully structured and functional. The details were also made as much as possible. Its features are:

The hatch can be opened and closed.
The trunk can be connected.
You can connect by moving the umbilical connection.
Here's how to assemble this SpaceX Dragon capsule and trunk.

Insert the inner part of the capsule into the outer part. At this point, pay attention to the direction of the hatch.
Install the hatch. At this time, pay attention to the direction.
The trunk, first rotates the umbilical connection outward.
Rotate the bottom part.
Combine the holes in the bottom of the capsule with the projections on the trunk according to the direction.
Rotate and connect the umbilical connection.
Capsule and trunk are detachable.
Printing on Prusa and building process - https://youtu.be/Ome9Kdt-b6Y
Ender3 pro - https://youtu.be/3rhw3X0zM8E
CR10s pro - https://youtu.be/SkA7i96_dOM
Bluer - https://youtu.be/wgxMnjPXPHU

This design is designed to be mounted on a Falcon9 rocket that I designed. Here is the link to download the Falcon9 rocket.
https://cults3d.com/en/3d-model/game/space-x-falcon-9-rocket

I look forward to an era where space travel is possible as soon as possible.

Scale 1 : 66

Size, when all parts are fitted X 76mm, Y 76mm, Z 123mm
