Flsun 13 Plus bed leveling knobs/wheels LARGE (probably works with Creality CR 10 and others) 3d model
Flsun 13 Plus bed leveling knobs/wheels LARGE (probably works with Creality CR 10 and others) 3d model

Flsun 13 Plus bed leveling knobs/wheels LARGE (probably works with Creality CR 10 and others)

This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:3254327.

This is a bed leveling wheel for the FLSUN i3 plus or C plus. The stupid little wing nuts (or if you read the instructions for building this "butterfly nuts") that come with it are hard to adjust and annoying. These make the bed leveling screws as smooth as butter when making adjustments. These wheels a a bit over 2 inches in diameter. You will need to print 4 of them and will need some M3 nuts. These print with a sacrificial bridge in the screw hole. it is 1 layer thick (when printing in .3) and will need to be poked out with a small screwdriver or m3 screw. The tolerances on this part were fairly tight when I printed them. You will need to pull the nut into the wheel using an m3 screw and a wingnut threaded backward.


Discussions
Toadiloader
toadplays20

It will not work with CR10. CR10 uses m4x40 screws, and this uses m3.

Flsun 13 Plus bed leveling knobs/wheels LARGE (probably works with Creality CR 10 and others)

9 downloads · 5 years ago
