Design and Model

This model is for the standard version of the Creality Hi - CFS overhead mount.

The model includes all parts to mount the CFS on top of the Creality Hi. The design is very robust and can safely hold the CFS above the Creality Hi. This model is based on the Ace-Pro overhead mount which have more than 10k downloads. You can follow the link to see user comments. (https://www.makeronline.com/en/model/KOBRA-3%20ACE%20OVERHEAD%20MOUNT%20V2/31836.html).

The standard version of the Hi-CFS mount offers the following features:

• Extra desk space;
• Tool tray and other add-ons (free download - see the links below);
• A buffer holder. The buffer holder allows a quick connect and disconnect between the CFS and an external spool (free download - see the links below);
• External spool mount (free download - see the links below);
• Side trays, side containers, tool holders and more (free download - see the links below).

An ultimate version of the Hi-CFS mounts is also available. The ultimate version offers all of the above features as well as:

• Dual drawers with grid-finity style customizable inserts;
• Dual build plate holders;
• Clips for mounting an LED and more.

Ultimate edition link: https://cults3d.com/en/3d-model/tool/creality-hi-cfs-overhead-mount-ultimate

ASSEMBLY INSTRUCTIONS

The model includes a print setting file and detailed instructions in a pdf file.

ADD-ONS

Here is a list of free add-ons for use with the Creality Hi - CFS overhead mount

NEW AND RECOMMENDED: External spool holder with interchangeable spindles(4 models):

Can be used on same side as CFS Buffer holder V1 and V2: https://www.crealitycloud.com/model-detail/683c96cad9bc4f366d299cbe?source=22

Cannot be used on same side as CFS Buffer holder V1 and V2:

https://www.crealitycloud.com/model-detail/683a57f3d9bc4f366d17abfa?source=22

https://www.crealitycloud.com/model-detail/683c9961d9bc4f366d29b9fb?source=22

https://www.crealitycloud.com/model-detail/683c9c30d9bc4f366d29d9d5?source=22

NEW: CFS BUFFER HOLDER V2 (now works with cables supplied with the CFS and Hi but the buffer is mounted on the Left side) : https://www.crealitycloud.com/model-detail/682fb366aef686d178cc3153?source=22

CFS BUFFER HOLDER: https://www.crealitycloud.com/model-detail/68142620bf737a7e52c9a158?source=22 EXTERNAL SPOOL HOLDER: https://www.crealitycloud.com/model-detail/681428f0bf737a7e52c9b498?source=22 MODULAR TOOL TRAY: https://www.crealitycloud.com/model-detail/68142a1cf8576ee3f905bd43?source=22 SIDE CONTAINER: https://www.crealitycloud.com/model-detail/68142ad7bf737a7e52c9c205?source=22 SIDE TRAY: https://www.crealitycloud.com/model-detail/68142b7fbf737a7e52c9c689?source=22 TOOL TRAY: https://www.crealitycloud.com/model-detail/68142c20bf737a7e52c9cb0a?source=22

External spool mount with interchangeable spindles for various size spools: https://www.crealitycloud.com/model-detail/683a57f3d9bc4f366d17abfa?source=22

PRINTING TIME AND FILAMENT

Standard model Print time (base unit) 22.5 hours Filament: 1 kg

Ultimate model: Print time 1 day 18 hours Filament: 1.8 kg

EXTERNAL HARDWARE

The model does not require any external hardware except for 6 wood screws for the LED clips (no.6 x 1/2 inch 3.5 mm x 13.5 mm). A 1.5m 6pin 485 cable will be required. (NO CABLE NEEDED WITH THE CFS BUFFER V2 - SEE ABOVE):

See link: https://www.amazon.com/Creality-CFS-150cm-Printer-Accessories-Connecting/dp/B0DT9MSTQW/ref=sr_1_1?crid=WDOKQHZCV9TK&dib=eyJ2IjoiMSJ9.TZSDLwS2yvETySMKT9IGJlamsncssTAPoBXXbeVGxvebw9R4X0wCXLKx0Ge-kWF3xkXBZIMWFd166EZL--bQadGppORbIvp96vcuJpfkhzaSqcKI7YdiT7WwymoFksuhIQjVbzLMlzU2Wo9FqaBx4_LfcYi8B9hO6NcNfxNAUYI8cCzDNCa0Dw9tN8ndaH-eyeb9rkKxt90E8lpjyjjvTMerOZ_5V2P3WqqFz9XQJAo.lRYJwDSRbVWRdZ2eUjijO7bkFPaM54wqGXOYFwBiGv8&dib_tag=se&keywords=4+ft+6+pin+485+3d+printer+cable&qid=1746158408&sprefix=4+ft+6+pin+485+3d+printer+cable%2Caps%2C81&sr=8-1

3D PRINTING

IMPORTANT – PRINT SETTINGS

I upload a print setting files for all my models. The print settings has the parts positioned for correct printing and with support painted. Use “Tree Manual” as the support setting. I strongly recommended you use my print setting file. If not, I will not be able to assist you if there is an issue when printing. From experience, many of the issues with printing my models are on account of users not using my print settings.

3D PRINT SETTINGS

I use the following settings and materials to print this model: Infill % : 15% (no need for more) Nozzle diameter: 0.4 mm Layer height: 0.2 mm standard Material: PLA is recommended as its more rigid. PETG or other filaments may cause the part to deform or may not work with the built-in tolerances. PLA-CF and PETG CF and other materials often print too wide and cause parts not to fit.
