Cura Infill Sample Swatches

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6270850.

13 infill sample swatch cards for Cura infills:

Grid, Lines, Triangles, Tri-Hexagon, Cubic, Cubic Subdivision, Octet, Quarter Cubic, Concentric, Zig Zag, Cross, Cross 3D, Gyroid

Recommended slicer settings:

• Layer Height 0.2
• Top/Bottom Thickness 0.4
• Top Layers 0
• Wall Thickness 1.2 (Wall Count 3 with Line Width of 0.4)
• Print Thin Walls yes
• Infill Density 35%

Included .3mf file is preconfigured with Cura 5.0

When loading the .stl split the model into separate objects using the Mesh Tools plugin. Select each swatch tile and add a per model setting for Infill Pattern, set to the appropriately to match the tile name.

Swatch format inspired by Customizable Filament Swatch by makkuro and Infill Swatches by crammers
