Autodesk Fusion 360 Infill Sample Swatches

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6270884.

Did you know Fusion 360 has a built in slicer!

13 infill sample swatch cards for Autodesk Fusion 360 slicer.

Gyroid, Rectilinear, Star, Honeycomb, Squares, Spherical, RhombicDodecahedron, ElongatedDodecahedron, TruncatedDodecahedron, Flower, Rhombus3D, Rhombille, Auxetic

Usage Open the included Autodesk Fusion 360 .f3d file and go to the Manufacture Workspace. You will need to edit the Setup to change the printer selection, and then edit Print Settings for your printer/material as appropriate. There are separate Body Presets for each infill type which are assigned to each swatch.

Recommended slicer settings:

• Layer Height 0.2
• Shell > Number of Perimeters 3
• Shell > Number of Top Layers 0
• Shell > Number of Botton Layers 2
• Infill > Infill Density 35%
