This model is restricted by licensing terms.

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4821171.

A cable guide for using the USB TypeC U-Shaped Cable while charging. (Requires USB TypeC U-Shaped Cable.)

This cable guide allows you to pull the cable out of the top of the switch body.

Protects USB Type C connections.

Cable thickness is 4 mm or less in diameter Also supports flat cables

Please print one of the following.

  • UsbC_U-ShapedGuide.stl normal version

  • UsbC_U-ShapedGuide1mm.stl It's a little bigger When a 1mm thick cover is attached to the Switch body

USB TypeC U-Shaped Cables


[Japanese]

充電しながらUSBTypeCU字型ケーブルを使用するためのケーブルガイド。 (USB TypeC U字型ケーブルが必要です。)

このケーブルガイドを使用すると、スイッチ本体の上部からケーブルを引き出すことができます。 USB TypeC接続部分を保護します。

ケーブルの太さは直径4mm以下です フラットケーブルもサポート

次のいずれかを印刷してください。

UsbC_U-ShapedGuide.stl 通常版

UsbC_U-ShapedGuide1mm.stl 少し大きいです スイッチ本体に厚さ1mmのカバーを取り付けた場合

USB TypeCU字型ケーブル https://www.amazon.co.jp/gp/product/B07V2CKPLG/ https://www.amazon.co.jp/gp/product/B08495RVYM/
