AA to 3R12 Battery Adapter

by
reitermarkus
Follow
Follow
Remix Model
reitermarkus
reitermarkus
|
Image 1 of 3
AA to 3R12 Battery Adapter 3d model
reitermarkus
reitermarkus
|
Image 1 of 3
AA to 3R12 Battery Adapter 3d model
2D
3D
Makes
AA to 3R12 Battery Adapter 3d model
AA to 3R12 Battery Adapter 3d model
AA to 3R12 Battery Adapter 3d model

Items needed:

  • tabs from old battery
  • two double-contacts (one may need to be inserted upside-down, depending on which type you have)
  • two single-contacts (positive and negative)

Instructions:

  • solder wire between long tab and negative single-contact
  • insert tab from inside through the opening, followed by the negative single-contact
  • insert short tab, followed by the positive single-contact
  • insert double-contacts
