RFID Tag Scanner Case

by

mjf55

Follow
Follow
Remix Model
Like
RFID Tag Scanner Case 3d model
2D
3D
Makes
Be the first to upload a make
This model is restricted by licensing terms.
0 Likes2 DownloadsMarch 5, 2022
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2483023.

I wanted to test reading NTAG213 RFID cards, so looking through the internet, I found the schematic to connect a PN532 card to an Arduino Nano using the SPI interface. With code available thru ebay, I have a functioning card reader.

Created in openSCAD

Thanks to raster and is Arduino Nano Holder , thing https://www.thingiverse.com/thing:1586850 for the code for the basic nano holder. and KitWallace for showing how to use the fonts
