Nicknamed "Pompidou", you are looking at the 4th design from Amsterdam based CERAMIC AUDIO, from Jairo Bambang Oetomo. Jairo created this design after his first year as a speaker designer.

Parts needed:

• Audio Driver with 4x 110mm bore hole diameter
• speaker spike feet m6
• Amplifyer
• Spade Connectors
• Crimp
• 4 x 20mm m3 bolts and nuts

INSTRUCTIONS:

Enclosure

1. Print and assemble like on the picture with the part names. Use an airtight glue like clear epoxy
2. in Driver_Mount.stl create 4 x 1.5mm holes and glue wire with spade connector so that the spade protrudes from the driver mount.
3. solder the wires to the audio driver (or do this before step 2, whatever suits)
4. screw the spikes m6 feet to the bottom of the speaker with optional kit to ensure an airtight fit

Electronics

1. Create a Sigma Studio Project and create a 2.5KHz crossover and EQ to your liking.
2. Wire the amplifyer with female spades and connect them to the driver.
3. power the amplifyer and 🎵
