Dome Housing for Underwater Pan and Tilt Camera

Model This is a model to house a 3 axis pan and tilt kit to suit a 200 mm diameter acrylic dome. Mounts on the side hold 25 mm OD acrylic tubes that house LED strips for underwater lighting. It's designed to mount underneath my 3D printed catamaran utility boat design here.

Build Video

Print Settings

• Large parts – 0.6 mm nozzle, 0.36 mm layer height, no supports
• Small parts - 0.4 mm nozzle, 0.2 mm layer height

Hardware Required

• 200 mm vacuum formed acrylic dome
• 2 x 300 mm x 25 mm OD acrylic tube
• 8 x M5 x 70 mm bolts
• 8 x M5 nuts
• 4 x M3 x 15 screws
• 4 x M3 nuts
