Clifford K

Sculpfun S6 Pro Electronics Case with Fan

by

clifford.kasper

Follow
Follow
Like
Sculpfun S6 Pro Electronics Case with Fan by clifford.kasper full viewable 3d model
Loading preview...
2 Likes0 DownloadsApril 1, 2022


Community Uploads

No photos added yet, be the first to upload a photo!


2 Likes0 DownloadsApril 1, 2022

Community Uploads

No photos added yet, be the first to upload a photo!

I've modified my Sculpfun S6 Pro and I wanted a better electronics enclosure. This enclosure uses a front plate to better access the board. The case accommodates the MKS V1.0 board that came standard with the laser. Additionally, I added a 40mm fan to the front plate; 5v fan that plugs directly into the extra 5v connector on the board. The fan is mounted to push air directly onto the board and exhaust to the left. This can probably fit the Sculpfun S9 (I think it uses the same electronics and mounting). Hardware Brass Inserts 40mm 5v fan m3 bolts (nuts for fan if you don't want to use inserts) Amazon Links brass inserts => https://www.amazon.com/dp/B08Z89R4HP?psc=1&ref=ppx_yo2_dt_b_product_details fan => https://www.amazon.com/dp/B07KRSJVP7?ref=ppx_yo2_dt_b_product_details&th=1 bolts => https://www.amazon.com/gp/product/B07H4MG7TC/ref=ppx_yo_dt_b_search_asin_title?ie=UTF8&psc=1 This was designed in FreeCAD. Print Information: Prusa i3 MK2S 0.2 PETG No Raft/Supports 10% infill
