Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5607155.
This is one of my keyboard designs I made with my keebcu keyboard customizer. It is a 75+% Q1 Layout mechanical keyboard which can be printed on smaller printers such as Prusa Mini. 75Q1iso means 75% size with Keychron Q1 style keyboard with ISO layout. This model additionally has a top frame to hide the switches. This gives a nice clean look.
If you want to build the complete keyboard at once, I added the complete models also. This design uses an Teensy2 as controller. If you want some customizations, check out the repository and modifiy the keyboard files or build yourself a custom one.
OpenSCAD files and documentation: https://github.com/andimoto/keebcu
Wiring Diagram can be found here: https://github.com/andimoto/keebcu/blob/develop/wiring_sheets/andimoto75Q1-iso/andimoto75Q1_iso_teensy2_wiring.pdf
Firmware can be found here: https://github.com/andimoto/keebcu/tree/develop/qmk-builds/andimoto75Q1-iso
Firmware Sources can be found here: https://github.com/andimoto/qmk_firmware/tree/andimoto-keyboards/keyboards/andimoto/andimoto75Q1iso
You need:
- keyboard case (left & right or complete) - lid (left & right or complete) - risers - wrist rest (optional) - cherry mx style switches - fancy keycaps (for this the Q1 iso keycaps fit directly) - costar stabilizers - glue - wires (thin) - 1N4148 diodes - 12x m3x8 screws for lid - 20x m2.5x8 screws for frameI also added the complete model which can be printed on bigger printers. Keyboard is 325mm in length.
If you have questions write me! Have fun building it!!
