This is housing for the BigTreetTech 12864 Display. Might fit other versions of the 12864 as well, not tested.

Two versions included: with and without the reset button.

Be careful: once the printed button is put on the switch, it will never come off again without destroying the switch. That is why I use the version without reset button.

The X on the button doesnt look that good printed. You might want to use a smaller nozzle or change the model.

STEPS included.

Printing instructions:

  • Can be printed without supports
  • Mirror the bracket once, you need two in total.

Hardware needed: 4x M3x10-12 to fix the display in the enclosure 2x M3x10-16 to fix the thing to the 3030 profile 2x M3 3030 nuts
