Multiboard Bolt Generator

3.6K downloads · 2 years ago · Watch this video to see the Multiboard Bolt Generator in action and learn how to use it: https://you

This model is restricted by licensing terms.

View license.

Description

Watch this video to see the Multiboard Bolt Generator in action and learn how to use it: https://youtu.be/if_obH4gU4k

NOTE You DO NEED to unzip the file. In the video, it is explained that you don't need to do this. But this info is now out of date. It will also work in Blender 5.0

The Multiboard Bolt Generator is a powerful Blender Addon that allows you to instantly generate custom Multiboard bolts. With this tool, you can:

Choose from Regular Bolts, T-Bolts, or Folded-Bolts.
Select any head type or hole type.
Create threads of any size.
Adjust the tolerance to your needs.
And more...

This object is part of Multiboard, a FREE "all in one" organization system with 900+ parts, that combines pegboard holes, honeycomb snaps, Gridfinity like bins, threads, brakes, and much more.

Explore and build the coolest, most adaptable workshop at https://multiboard.io

Tags:

Discussions

pharocious_maker1 year ago

Would it be challenging to add the Multipoint head to the generator? I have been exporting the raw screw shapes and creating my own that way, but adding the head to the generator would be a great addition.

adlaws1 year ago

Just a heads up, in Blender 4.4.0 the add-on fails to install, complaining about Missing manifest from: C:\Users\USERNAME\Downloads\Multiboard Bolt Generator.zip in the logs. I've tried on both Windows and Linux and get the same result. Maybe some new requirement in the latest versions of Blender?

Mule1 year ago

Getting the same issue , do you know of any fix ?

Mule1 year ago

For anyone who had the same problem. Note that when downloading the bolt generator from Thangs , there is a top level zip file and buried within that there is another zip file MultiboardBolts 0.1.2 , I used that zip as the add on and it worked for me

joseph.fellow7 months ago

THANKS. Worked for me (I thought it was a Mac thing)

xperties1 year ago

Thank you so much. I sat here and restarted the app and went through every possible menu thinking I was missing something. This should really be updated in the video.

luditte1 year ago

Totally helped thx

Ravenwarrior20145 months ago

Got to say I'm not a happy camper. Just spent almost $100 for the upgraded membership to download the bolt generator. Does not install correctly in Blender 5.0. Using the 0.12 zip makes no difference, missing maintainer field. Anyone have a solution for this yet? I do see where Mule got it to work.

koharker8 months ago

great generator! two humble requests:

Add the "locking bolt" thread size to this in addition to "big", "mid", and "small.
Add option to add coin slot for screwing in bolts to any bolt (headed and headless)

cassielisius8 months ago

I signed up for membership for this generator specifically and downloaded blender to use it - followed instructions for download and adding the extension to blender and it doesn't work...
