Prusa-Mini Z Bottom for SKR Mini E3

by

FL62michi

Follow
Follow
Remix Model
Like
F
FL62michi
Image 1 of 2
Prusa-Mini Z Bottom for SKR Mini E3 3d model
2D
3D
Makes
Prusa-Mini Z Bottom for SKR Mini E3 3d model
Prusa-Mini Z Bottom for SKR Mini E3 3d model
This model is restricted by licensing terms.
2 Likes7 DownloadsSeptember 6, 2022
This model is restricted by licensing terms.


Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:4147357.

Remixed Prusa Mini Bottom Case for use with SKR Mini E3 Board

My Prusa Mini build started as something to do with some extra parts I had lying around from an i3 clone, while waiting for my actual Prusa Mini Order to ship in the spring.

I had some typical 220x220 heat-beds and build surfaces, lots of 300 and 320mm guide rods, and NEMA 17 steppers. Had a few E3D V6 clones, so I ordered up a SKR Mini E3 board and 3.5 Touchscreen display, and started remixing parts to put something together. Had to order the 10mm guide rods and bearings, but it's come together nicely. As of 02/22/2020, I just need to finish adjusting the firmware file for this configuration, and to display the touchscreen in Portrait Mode to fit this form factor.

What i've ended up with is 220mm cube build volume printer (similar to original i3 or Ender 3, but in a much smaller frame. We will see how well it works, but a bowden fed V6 and TMC2209 steppers can't be too bad!
