Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6158902.
This is a Work In Progress - See Below
Non-Commercial License Please send me a message if you want a commercial license for the A2 Bikes SP design, a model for another bike, or have any other questions.
RECOMMENDATIONS: I recommend printing this with a resin printer. A majority of my rids have been self printed using resin, without failures. The first ride with an FDM version of the container purchased via Craftcloud resulted in a cage failure when crossing a bridge connection.
Features:
- Rear slot to place number card on bike.
- Large storage capacity.
The current model is v5. This was designed and tested for the A2 Bikes SP, with inspiration taken from the Bontrager Speed Concept Draft Box II. The A2 Bikes SP has a 12 degree seat post, if you would like to test this with other Triathlon bikes, please provide feedback!
Current Revision Notes:
- Removed the cage attaching the lower body directly to the bike. Split the v4 body in half to to make it easier to retrieve items.
Revision Notes: v5 -- Remove cage, change body and lid heights. v4 -- New Lid Pin secures the lid in place, locked with safety pin. v3 -- Lid now sits over body, making it a little more water resistant. v2 -- Updated file to follow tire radius. (Photo without number plate) v1 -- Lid sits inside body, and does not follow tire radius. (Photo with number plate)
